ROLAND SV8 / SV12 / SV 15 電腦割字機


>
小台輕巧、簡易使用的切割機,適合學校、商店、辦公室及家庭來使用。
非常適合廣泛的應用於廣告、標籤貼紙、車身貼紙、衣服熱轉印及櫥窗展示等。
完整的解決方案,滿足您所有的需求。
隨機附贈 Roland CutStudio 切割軟體。
可搭配標準桌上型印表機,作影像輪廓切割,不需要其他額外設備。
拼版分割功能可讓 STIKA 能夠分割高達 64 部份的大圖 (水平和垂直各 8 個)。
材質導引線能夠幫助確保校正材質的位置,以生產高品質的成品。
USB 傳輸介面能夠和電腦作簡易的連線。





Software

1

Roland CutStudio 軟體

每一台 STIKA 均會搭配一套最新版簡易使用的 Roland CutStudio,從簡單的文字到彩色圖形, CutStudio 都能夠簡單的完成,使用 Using CutStudio,您可以畫圓和曲線圖及於弧形上增加文字並編輯,也可輸入 jpg 或是 bmp 的相片或是影像圖形,結合長方形、圓形、多重線及曲線成為更多複雜的圖形, CutStudio 相容於 Windows 98 SE/Me/2000/XP 並內建 Windows 版的 Adobe® Illustrator® 9/10/CS/CS2 和 CorelDRAW® 10/11/12及 Mac版的 Adobe® Illustrator® 9/10/CS/CS2 的外掛軟體,讓使用者能夠直接由這些軟體直接傳送資料至切割機。
1

Roland STIKA 螢幕導航操控面板

STIKA 隨機配備 STIKA Navi 螢幕導航操控面板軟體,獨特的功能甚至能做簡易的切割和有助於材質的最大使用,使用 STIKA Navi 螢幕導航操控面板軟體和您的滑鼠,每一次您可以移動切割刀至適當的起始位置做精密的切割,STIKA 螢幕導航操控面板可從機器的“Cutting Setup” 或是“Set up the printer”的選項讀取選項資訊。
1

Spec
機型 SV-15 SV-12 SV-8
切割方式 Friction feed
最大切割範圍 Width: 340 mm (13-3/8 in.) Length: 1000 mm (39-5/16 in.) Width: 250 mm (9-13/16 in.) Length: 1000 mm (39-5/16 in.) Width: 160 mm (6-1/4 in.) Length: 1000 mm (39-5/16 in.)
可使用材質尺寸*1 Width: 360 to 381 mm (14-1/8 to 15 in.)
Length: 1100 mm (43-1/4 in.) or less
Width: 280 to 305 mm (11 to 12 in.)
(A3 length, A4 width) Length: 1100 mm (43-1/4 in.) or less
Width: 280 to 305 mm (11 to 12 in.)
(A3 length, A4 width)
Length: 1100 mm (43-1/4 in.) or less
Width: 200 to 215 mm (7-13/16 to 8-7/16 in.)
(A4 length)
Length: 1100 mm (43-1/4 in.) or less
最大切割速度 12 to 100 mm/sec. (7/16 to 3-7/8 in./sec.) 12 to 40 mm/sec. (7/16 to 1-9/16 in./sec.) 12 to 40 mm/sec. (7/16 to 1-9/16 in./sec.)
可使用材質的種類*2 Vinyl chloride material (material section thickness alone is 0.1 mm or less, thickness including backing paper is 0.3 mm (0.012 in.) or less) Label paper
(Thickness including backing paper is 0.3 mm (0.012 in.) or less)
傳輸介面
USB 1.1
電源供應 / 電源損耗 Dedicated AC adapter Input: AC 100 V 10%, 50/60 Hz 1.7A Output: DC 19 V, 2.1 A / Approx. 20 W (including AC adapter)
機器外觀尺寸 522 (W) x 205 (D) x 115 mm (H)
(20-5/8 (W) x 8-1/8 (D) x 4-1/2 in. (H))
440 (W) x 205 (D) x 115 mm (H)
(17-3/8 (W) x 8-1/8 (D) x 4-1/2 in. (H))
340 (W) x 205 (D) x 115 mm (H)
(13-3/8 (W) x 8-1/8 (D) x 4-1/2 in. (H))
機器重量 3.3 Kg (7.3 lb) 2.7 Kg (6 lb) 2.2 Kg (4.9 lb)
噪音值 60 dB (A) or less (according to ISO7779)
操作環境 Temperature: 5 to 40°C (41 to 104°F), humidity: 35 to 80% (no condensation)
機器配件 AC adapter, power cord, USB cable, replaceable blade protector, blade, blade holder, pin, test-use material, test-use application tape, CD-ROM, user's manual
*1 Depending upon the type, material that is 500 mm (19-5/8 in.) or longer may shift during cutting.
*2 You may also be unable to cut some types of material.
隨機附贈軟體 Roland CutStudio Roland CutStudio Plug-in for Adobe® Illustrator® Roland CutStudio Plug-in for CorelDRAW®
作業系統 Windows® 98SE/Me/2000/XP Windows®, Mac OS Windows®
應用軟體 Adobe® Illustrator® 9/10/CS/CS2 CorelDRAW® 10/11/12
