ROLAND GX-24 電腦割字機
 |
||
 |
 |
 |
 |
 |
 |
 |
 |
| 專業切割機，簡易的使用於招牌、車體廣告及賣場展示等方面。 | |
| 產能最大，切割速度高達850mm (33")/sec。 | |
| 機械解析度0.0125mm/step (0.00049") 的精密切割。 | |
| 最重達 350 克的切割刀壓特性，甚至連較厚的材質都可切割 | |
| 隨機附贈 Roland CutStudio*1軟體，針對Roland切割機開發的切割排版軟體。 | |
| 自動四點定位功能*2，每一次都能夠準確的輪廓切割。 | |
| 使用USB 或是RS-232 Serial，簡易的與電腦連線。 | |
| AdobeR IllustratorR and CorelDRAWR*3外掛的軟體。 | |
| 可使用的三種尺寸: 1372mm、1178mm 和 915mm (54", 46" and 36")。 | |
| *1 相容於 Windows®98SE/Me/2000/XP。 *2 此系統接受經由 Roland CutStudio 軟體和 Adobe Illustrator 的外掛軟體。 *3 外掛軟體相容於 Adobe Illustrator 9/10/CS/CS2 for Windows、CorelDRAW 10/11/12 for Windows 和 Adobe Illustrator 9/10/CS/CS2 for Macintosh。 |
|
 |
| 機型 | GX-500 | GX-400 | GX-300 |
| 機械結構 / 驅動方式 | Friction feed / Digital control servo motor | ||
| 最大切割範圍 | Width: 1195 mm (47 in.) Length: 24998 mm (984-1/8 in.) |
Width: 1000 mm (39 in.) Length: 24998 mm (984-1/8 in.) |
Width: 737 mm (29 in.) Length: 24998 mm (984-1/8 in.) |
| 可接受材質寬度 | Min. 90 mm (3-1/2 in.) Max. 1372 mm (54 in.) |
Min. 90 mm (3-1/2 in.) Max. 1178 mm (46 in.) |
Min. 50 mm (2 in.)/Max. 915 mm (36 in.) (50 to 540 mm (2 in. to 21 in.), 582 to 915 mm (23 in. to 36 in.)) |
| 能被裁刀切割的寬度 |
0 to 1270 mm (0 in. to 50 in.) | 0 to 1067 mm (0 in. to 42 in.) | 0 to 812 mm (0 in. to 32 in.) |
| 刀具 | Special blade for CAMM-1 series | ||
| 最大切割速度 | During cutting: 850 mm/sec. (in all directions) During tool-up: 1202 mm/sec. (in 45 direction) | ||
| 切割速度 / 切割刀壓 |
10 to 850 mm/sec. (in increments of 10 mm/sec.) / 20 to 350 gf | ||
| 機械解析度 | 0.0125 mm/step (0.000492 in./step) | ||
| 軟體解析度 | 0.025 mm/step (0.000984 in./step) | ||
| 距離精度 (*1) |
Error of less than ± 0.2% of distance traveled, or 0.1 mm (0.00394 in.), whichever is greater | ||
| 重複精度 (*1) (*2) (*3) | 0.1 mm or less | ||
| 傳輸介面 | Serial (RS-232C-compatible), USB (Rev 1.1) | ||
| 記憶體 |
2 MB (buffer size: 8 MB) | ||
| 電源供應 / 電源功率 | AC 100V to 240V ± 10% 50/60 Hz 1.2A / Approx. 100W | AC 100V to 240V ±10% 50/60 Hz 1.1A / Approx. 95W | |
| 機器外觀尺寸(含腳架) | 1602 mm (W) x 727 mm (D) x 1113 mm (H) (63-1/16 in. (W) x 28-5/8 in. (D) x 43-13/16 in. (H)) |
1407 mm (W) x 727 mm (D) x 1113 mm (H) (55-3/8 in. (W) x 28-5/8 in. (D) x 43-13/16 in. (H)) |
1144 mm (W) x 727 mm (D) x 1113 mm (H) (45-1/16 in. (W) x 28-5/8 in. (D) x 43-13/16 in. (H)) |
| 機器重量(含腳架) | 55 kg (121.2 lb.) | 51 kg (112.4 lb.) | 44 kg (97 lb.) |
| 機器配件 | Power cord, blade holder (XD-CH2), pin, blade, alignment tool, cable clamp, replacement blade for sheet cutter, USB cable, Roland software CD-ROM, setup guide, user's manual | ||
*1 According to material and cutting conditions as specified by Roland DG Corp.
|
| 隨機附贈軟體 | Roland CutStudio | Roland CutStudio Plug-in for Adobeｮ Illustrator® | Roland CutStudio Plug-in for CorelDRAW® |
| OS | Windows® 98SE/Me/2000/XP | Windows®, Mac OS | Windows® |
| Application Software | — | Adobe® Illustrator® 9/10/CS/CS2 | CorelDRAW® 10/11/12 |
 |
| 切割刀 |
ZEC-U1715 |
For cutting sandblast stencils for friction feed, maximum 1.00mm thickness, offset value 0.25mm, 5-pack | ||
| ZEC-U3017 |
For cutting sign vinyl in general plus cutting small letters or intricate designs, offset value 0.175mm, 3-pack | |||
| ZEC-U5022 |
For cutting sign vinyl in general, offset value 0.25mm, 5-pack | |||
| ZEC-U5025 |
For cutting thick, reflective and fluorescent vinyl, as well as sign vinyl in general , offset value 0.25mm, 5-pack | |||
| 切割刀座 |
XD-CH2 |
For sign vinyl in general as well as thicker material. Performs well for detailed cutting. Blade holder with blade extention adjuster, made of aluminum | ||
| XD-CH3 |
For sign vinyl in general. Blade holder with blade extention adjuster, made of resin | |||
| 置紙架 |
HS-500 |
For GX-500, 1 set | ||
| HS-400 |
For GX-400, 1 set | |||
| HS-300 |
For GX-300, 1 set | |||
| 序列埠傳輸線 | XY-RS-34 | 3m (9.8ft) | ||
